Design Consultation & Project Scoping
We begin by understanding your project requirements — including part design, material selection, production volume, and performance goals.
Our engineering team collaborates closely with yours to ensure that every mold, die, or prototype is built for manufacturability, efficiency, and long-term performance.
Deliverable: 3D CAD design proposal, DFM (Design for Manufacturability) report, and project timeline.
Tool Design & Material Selection
Once specifications are finalized, our design engineers in Hsinchu, Taiwan develop detailed tool and die drawings using advanced CAD/CAM software.
We recommend optimal materials such as P20 for low-volume production or H13 for high-volume, high-pressure applications, balancing durability with cost efficiency.
Deliverable: Final tool drawings and steel selection approval.
CNC Machining & EDM Manufacturing
Our precision machining centers and EDM equipment create the core and cavity components with micron-level accuracy.
Each mold undergoes rigorous dimensional verification to ensure precision alignment, surface finish, and component fit.
Deliverable: Machined tool components and in-process inspection report.
Assembly & Mold Trials
Tools are assembled, bench-fitted, and tested in-house. We conduct trial shots to verify part quality, tolerances, and mold performance under production conditions.
This iterative testing phase ensures that every tool performs flawlessly before shipment.
Deliverable: Sample parts, trial reports, and dimensional validation results.
Quality Assurance & Final Approval
Each mold or die passes through a comprehensive QC process including hardness testing, coordinate measurement, and function testing.
Our commitment to zero-defect delivery ensures every product meets ISO-level standards and your specific production requirements.
Deliverable: Final inspection report and customer sign-off package.
Shipment & Delivery
Upon approval, we handle logistics directly through our US distribution arm, ensuring smooth customs clearance and reliable delivery.
Whether it’s a prototype mold or full production tool, you receive real-time tracking and dedicated support through final delivery.
Lead Times
Prototype molds: 18–20 days
Steel production molds: 25–40 days
Die-cast molds: 45–60 days
Progressive stamping dies: 25–35 days
